LTM236FL01 Samsung LCD panel replacement
$98,00
| Weight | 5 kg |
|---|---|
| MPN | |
| Brand |
SAMSUNG |
| Resolution | |
| Contrast Ratio | |
| Input Voltage | |
| Lcd Size |
Description
| product_name: | LTM236FL01 23.6″ a-Si TFT-LCD , Panel for SAMSUNG |
| Brand: | SAMSUNG |
| Panel model: | LTM236FL01 |
| Panel Type: | a-Si TFT-LCD , Panel |
| Panel Size: | 23.6 |
| Resolution: | 3840(RGB)×2160 , UHD |
| Display Mode: | PLS, Normally Black, Transmissive |
| Contrast Ratio: | 1000:1 (Typ.) |
| Surface: | Antiglare (Haze 25%), Hard coating (3H) |
| Brightness: | 300 cd/m? (Typ.) |
| Display Colors: | 16.7M (8-bit) , sRGB 100% |
| Viewing Angle: | 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) |
| Frequency: | 60Hz |
| Lamp Type: | 4 strings WLED Without Driver |
| Signal Interface: | eDP (4 Lanes) , 51 pins |
| Input Voltage: | 5.0V (Typ.) |
| RoHS: | RoHS Compliance |
| Active Area: | 521.28×293.22 mm |
| Outline: | 544.8×320.5×11 mm |
| Application: | Desktop Monitor |
| Response Time: | 14 (Typ.)(G to G) |
