Panasonic VVX26F157H00 LCD Panel Replacement
$888,00
| Weight | 11 kg |
|---|---|
| MPN | |
| Brand |
Panasonic |
| Resolution | |
| Contrast Ratio | |
| Input Voltage |
Description
| product_name: | VVX26F157H00 26.0″ a-Si TFT-LCD , Panel for Panasonic |
| Brand: | Panasonic |
| Panel model: | VVX26F157H00 |
| Panel Type: | a-Si TFT-LCD , Panel |
| Panel Size: | 26.0 |
| Resolution: | 1920(RGB)×1080 , FHD |
| Display Mode: | IPS, Normally Black, Transmissive |
| Contrast Ratio: | 1400:1 (Typ.) |
| Surface: | Antiglare |
| Brightness: | 900 cd/m? (Typ.) |
| Display Colors: | 1.07B (10-bit) |
| Viewing Angle: | 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) |
| Frequency: | 60Hz |
| Lamp Type: | 2 strings WLED Embedded (LED Driver) |
| Signal Interface: | LVDS (2 ch, 10-bit) , 51 pins |
| Input Voltage: | 12.0V (Typ.) |
| RoHS: | RoHS Compliance |
| Active Area: | 576×324 mm |
| Outline: | 613×364 mm |
| Application: | Medical Display |
| Response Time: | 10/8 (Typ.)(Tr/Td) |
